ci5300 Pro

Intermediate Pro Series Printer

The intermediate-level ci5300 Pro series printer is designed for 1 to 3 line printing applications with Macro and Normal drop sizes, achieving speeds of up to 11 m/s. It is housed in a robust stainless steel cabinet and includes a manual wash station as standard. With advanced communication capabilities, this printer is configured for use with all non-pigment ink types.

Get Quote

Brochure

Feature	Model Specification
Assumed usage (hrs/year)	3,000 to 6,000
Lines of print	1 - 3 lines
Character height	1.5mm to 12mm
Font height	5 to 25 dots
Line speed at 5 drop and 50 dpi	up to 9.8 m/s
Nozzle size	60μm or 75μm
Drop size	Normal (60μm), Macro (75μm)
ciLink	No
Inputs (photocell / shaft encoder / programmable)	2 / 1 / 8
Cabinet	Stainless Steel
IP Rating	IP55
Weight (including printhead)	18.3 kg
Warranty	30 months manufacturers warranty as standard (local conditions may vary).

Feature	ci5000 Series Specification
10.1" Touch Screen	Yes
ciEasyServ	Yes
ciPrecisionPlus	Yes
SmartFlush	Yes
ciSafeFill	Yes
Programmable Alarms / Relays	3 / 1
Conduit Length	9ft (2.75m) as standard
Service Interval	Service intervals of 8,000 hours or 18 months, depending on environment.
Languages	English, Spanish, French, German, Italian, Chinese (Simplified), Chinese (Traditional), Russian, Bulgarian, Kasakh, Macedonian, Arabic, Vietnamese, Korean, Japanese, Polish, Latvian, Lithuanian, Estonian, Turkish, Thai, Hebrew, Greek, Danish, Swedish, Norwegian, Finnish, Portuguese, Brazilian, Romanian, Croatian, Slovenian, Serbian, Albanian, Slovak, Czech, Hungarian, Dutch, Hindi, Urdu, Persian and Swahili.
Power	90 - 240V:(3 Amp), auto-ranging; 50 - 60Hz
Operating Temperature Range	5ºC to 45ºC (41ºF to 113ºF), ink dependent
Humidity Range	10% to 90%, non-condensing
Tank Sizes	1.9 liter ink tank; 2.25 liter make up tank
Ink and Make Up bottles	750ml error-proof ink and make up bottles
