ci5650
Harsh Environment Printer
Harsh environment printer with positive air pressurized enclosure and printhead for extreme dust or washdown environments. Includes all features and capabilities of ci5500.
| Feature | Model Specification |
|---|---|
| Assumed usage (hours/year) | 3,000 to 8,500 |
| Lines of print | 1 - 5 lines |
| Character height | 1.5mm to 12mm |
| Font height | 5 to 31 dots |
| Line speed at 5 drop and 50 dpi | up to 9.8 m/s |
| Nozzle size | 65ųm |
| Drop size | Normal (60ųm), Macro (75ųm) |
| PixelPlus | Yes |
| ciLink | Yes |
| Inputs (photocell / shaft encoder / programmable) | 2 / 1 / 8 |
| Cabinet | Stainless Steel |
| IP Rating | IP65 |
| Weight (incl. printhead) | 18.7kg |
| Warranty | 30 months manufacturers warranty as standard (local conditions may vary). |
| Feature | ci5000 Series Specification |
|---|---|
| 10.1" Touch Screen | Yes |
| ciEasyServ | Yes |
| ciPrecisionPlus | Yes |
| SmartFlush | Yes |
| ciSafeFill | Yes |
| Programmable Alarms / Relays | 3 / 1 |
| Conduit Length | 9ft (2.75m) as standard |
| Service Interval | Service intervals of 8,000 hours or 18 months, depending on environment. |
| Languages | English, Spanish, French, German, Italian, Chinese (Simplified), Chinese (Traditional), Russian, Bulgarian, Kasakh, Macedonian, Arabic, Vietnamese, Korean, Japanese, Polish, Latvian, Lithuanian, Estonian, Turkish, Thai, Hebrew, Greek, Danish, Swedish, Norwegian, Finnish, Portuguese, Brazilian, Romanian, Croatian, Slovenian, Serbian, Albanian, Slovak, Czech, Hungarian, Dutch, Hindi, Urdu, Persian and Swahili. |
| Power | 90 - 240V:(3 Amp), auto-ranging; 50 - 60Hz |
| Operating Temperature Range | 5ºC to 45ºC (41ºF to 113ºF), ink dependent |
| Humidity Range | 10% to 90%, non-condensing |
| Tank Sizes | 1.9 liter ink tank; 2.25 liter make up tank |
| Ink and Make Up Bottles | 750ml error-proof ink and make up bottles |
General Purpose Inks
- General Purpose Ethanol Black
- General Purpose Acetone Black
- General Purpose MEK Black
- General Purpose MEK Red
- General Purpose MEK Blue
Specialty Inks
- Alcohol Resistant Black
- Caustic Washable Black
- Caustic Washable Green
- Plastic
- Plastic Plus
- Acetone/Ethanol Black
- Direct Food Contact (DFC) Red
- Direct Food Contact (DFC) Blue
- Thermotropic Black to Red
Accessories and Consumables
- Alarm Beacons
- Photocells
- Shaft Encoders
- Positive Air Kit
- Bench and Floor Mountings
- Printhead Wash Station
- Printhead Brackets
Build Configurations
- Right Angled Printheads and Conduit Connections
- Multiple Conduit Lengths (9ft, 15ft and 20ft)
- Anaconda Conduit (Smooth Surface)
