ci5500 Pro

High Performance Pro Printer

The advanced ci5500 Pro series printer builds on the capabilities of the ci5300 Pro, offering high performance with the ability to print up to 5 lines of text, graphics, and barcodes at high speeds. It includes advanced connectivity features such as ciLink, ensuring seamless integration and communication. This printer is housed in a durable stainless steel cabinet and comes with a manual wash station as standard.

Brochure

Feature Model Specification
Assumed usage (hours/year) 3,000 to 8,500
Lines of print 1 - 5 lines
Character height 1.5mm to 12mm
Font height 5 to 31 dots
Line speed at 5 drop and 50 dpi up to 11 m/s
Nozzle size 60μm or 675μm
Drop size Normal (60μm), Macro (75μm)
ciLink Yes
Inputs (photocell / shaft encoder / programmable) 2 / 1 / 8
Cabinet Stainless Steel
IP Rating IP55
Weight (including printhead) 18kg
Warranty 30 months manufacturers warranty as standard (local conditions may vary).
Feature ci5000 Series Specification
10.1" Touch Screen Yes
ciEasyServ Yes
ciPrecisionPlus Yes
SmartFlush Yes
ciSafeFill Yes
Programmable Alarms / Relays 3 / 1
Conduit Length 9ft (2.75m) as standard
Service Interval Service intervals of 8,000 hours or 18 months, depending on environment.
Languages English, Spanish, French, German, Italian, Chinese (Simplified), Chinese (Traditional), Russian, Bulgarian, Kasakh, Macedonian, Arabic, Vietnamese, Korean, Japanese, Polish, Latvian, Lithuanian, Estonian, Turkish, Thai, Hebrew, Greek, Danish, Swedish, Norwegian, Finnish, Portuguese, Brazilian, Romanian, Croatian, Slovenian, Serbian, Albanian, Slovak, Czech, Hungarian, Dutch, Hindi, Urdu, Persian and Swahili.
Power 90 - 240V:(3 Amp), auto-ranging; 50 - 60Hz
Operating Temperature Range 5ºC to 45ºC (41ºF to 113ºF), ink dependent
Humidity Range 10% to 90%, non-condensing
Tank Sizes 1.9 liter ink tank; 2.25 liter make up tank
Ink and Make Up Bottles 750ml error-proof ink and make up bottles

General Purpose Inks

  • General Purpose Ethanol Black
  • General Purpose Acetone Black
  • General Purpose MEK Black
  • General Purpose MEK Red
  • General Purpose MEK Blue

Specialty Inks

  • Alcohol Resistant Black
  • Caustic Washable Black
  • Caustic Washable Green
  • Plastic Black
  • Plastic Plus Black
  • Special Plastic Black
  • Plastic Acetone/Ethanol Black
  • Direct Food Contact (DFC) Red
  • Direct Food Contact (DFC) Blue
  • Thermotropic Black to Red

Accessories and Consumables

  • Alarm Beacons
  • Photocells
  • Shaft Encoders
  • Positive Air Kit
  • Bench and Floor Mountings
  • Printhead Wash Station
  • Printhead Brackets

Build Configurations

  • Anaconda Conduit (Smooth Surface)
Ci5500 Pro Dimensions
