ci5650 Pro

Harsh Environment Printer

The ci5650 Pro series printer is designed for harsh environments, featuring a positive air pressurized enclosure and printhead to withstand extreme dust or washdown conditions. It includes all the features and capabilities of the ci5500, making it ideal for demanding applications in tough settings.

Get Quote

Brochure

Feature	Model Specification
Assumed usage (hours/year)	3,000 to 8,500
Lines of print	1 - 5 lines
Character height	1.5mm to 12mm
Font height	5 to 31 dots
Line speed at 5 drop and 50 dpi	up to 9.8 m/s
Nozzle size	60ųm or 75ųm
Drop size	Normal (60ųm), Macro (75ųm)
ciLink	Yes
Inputs (photocell / shaft encoder / programmable)	2 / 1 / 8
Cabinet	Stainless Steel
IP Rating	IP65
Weight (incl. printhead)	19 kg
Warranty	30 months manufacturers warranty as standard (local conditions may vary).

Feature	ci5000 Series Specification
10.1" Touch Screen	Yes
ciEasyServ	Yes
ciPrecisionPlus	Yes
SmartFlush	Yes
ciSafeFill	Yes
Programmable Alarms / Relays	3 / 1
Conduit Length	9ft (2.75m) as standard
Service Interval	Service intervals of 8,000 hours or 18 months, depending on environment.
Languages	English, Spanish, French, German, Italian, Chinese (Simplified), Chinese (Traditional), Russian, Bulgarian, Kasakh, Macedonian, Arabic, Vietnamese, Korean, Japanese, Polish, Latvian, Lithuanian, Estonian, Turkish, Thai, Hebrew, Greek, Danish, Swedish, Norwegian, Finnish, Portuguese, Brazilian, Romanian, Croatian, Slovenian, Serbian, Albanian, Slovak, Czech, Hungarian, Dutch, Hindi, Urdu, Persian and Swahili.
Power	90 - 240V:(3 Amp), auto-ranging; 50 - 60Hz
Operating Temperature Range	5ºC to 45ºC (41ºF to 113ºF), ink dependent
Humidity Range	10% to 90%, non-condensing
Tank Sizes	1.9 liter ink tank; 2.25 liter make up tank
Ink and Make Up Bottles	750ml error-proof ink and make up bottles
